Intelligent Oil Sealed Screw Vacuum Pump With Frequency Conversion Technology

Brand Name : Bebaios

Model Number : RV450~5400

Certification : N/A

Place of Origin : China

MOQ : 1

Price : N/A

Payment Terms : TT; Western Union; Alipay

Supply Ability : 6000 unit/month

Delivery Time : 1 week

Packaging Details : wooden case

Speeding : 450~5400 m³/h

Power : 5.5/7.5~90-125kw/hp

Starting : Variale Frequency

Ultimate Vacuum : 0.5/0.7 Torr/mbar

Contact Now

Innovative Intelligent Rotary Screw Vacuum Pump with Excellent Frequency Conversion Technology and Oil-Sealed Design

RV Series screw vacuum pumps are high-efficiency, energy-saving solutions developed for continuous industrial applications. Featuring specially matched rotors and rigid direct-drive technology, these pumps are designed to deliver optimal performance under specific pressure ranges. With low noise, low vibration, high vacuum levels, and low maintenance costs, the RV series is an ideal replacement for traditional piston and rotary vane vacuum pumps.

Key Specifications
Parameter Specification
Model RV900
Speed 900 (m³/h)
Ultimate VacuumTorr/mbar 0.5/0.7(mbar)
Voltage 380 V
Prequency 50Hz
Starting Frequency
Product Features
  • Excellent Frequency Conversion Technology
    Accurately adjusts operating pressure as process, time and vacuum requirements change. Energy-saving control algorithms are used to save an average of 50% energy over a wide range of air volumes (10-100%).
  • Intake Control Valve
    Prevents frequent operation, loading and unloading caused by rapid changes in gas consumption, and automatically adjusts vacuum gas volume according to frequency conversion drive to reduce costs.
  • Intelligent Control Cloud Service Platform
    Helps equipment enterprises develop new capabilities, such as intelligent detection, remote diagnosis, and equipment full life cycle management. By integrating applications, it can connect all parts of production management, encourage equipment enterprises to move to the cloud, and improve networked collaborative manufacturing.
  • Monitoring System
    Humanized vacuum pump monitoring system using a fully intelligent microcomputer control system. Current data can be viewed on any computer or mobile phone through an Internet browser. Features motor overload protection, stop delay protection, temperature stop protection, displays three filter running times, automatic fault diagnosis, and settable point control settings that can be integrated into your plant management system.

Other Product Series

Model Powerk (W/hp) Pumping Speed (m³/h) Air Intake Capacity (m³/min) Ultimate Vacuum (Torr/mbar) Voltage (V) Frequency (Hz) Cooling Method Starting Method Inlet Size Outlet Size Weightkg (Kg) Overall DimensionsL×W×H (mm)
RV450 5.5/7.5 450 7.5 0.5/0.7 380 50 Air Cooling Variable Frequency DN100 DN65 570
RV530 7.5/10 530 8.8 0.5/0.7 380 50 Air Cooling Variable Frequency DN100 DN65 580 1000×850×1100
RV630 11-15 630 10.5 0.5/0.7 380 50 Air Cooling Variable Frequency DN100 DN100 600 1000×850×1100
RV900 15-20 900 15 0.5/0.7 380 50 Air Cooling Variable Frequency DN100 DN100 850 1450×1200×1350
RV1100 18.5/25 1100 18.3 0.5/0.7 380 50 Air Cooling Variable Frequency DN100 DN100 860 1450×1200×1350
RV1300 22/30 1300 21.7 0.5/0.7 380 50 Air Cooling Variable Frequency DN100 DN100 900 1450×1200×1350
RV1560 30/40 1560 26 0.5/0.7 380 50 Air Cooling Variable Frequency DN200 DN150 1280 1550×1350×1540
RV1900 37-05 1900 31.7 0.5/0.7 380 50 Air Cooling Variable Frequency DN200 DN150 1300 1550×1350×1540
RV2100 45/60 2100 35 0.5/0.7 380 50 Air Cooling Variable Frequency DN200 DN150 1350 1550×1350×1540
RV3300 55-75 3300 55 0.5/0.7 380 50 Air Cooling Variable Frequency DN200 DN150 2000 2000×1800×1900
RV4100 75/100 4100 68.3 0.5/0.7 380 50 Air Cooling Variable Frequency DN200 DN150 2050 2000×1800×1900
RV5400 90-125 5400 90 0.5/0.7 380 50 Air Cooling Variable Frequency DN200 DN150 2300 2000×1800×1900

Intelligent Oil Sealed Screw Vacuum Pump With Frequency Conversion Technology

Product Applications
Machinery Manufacturing
Workpiece holding, conveying, clamping, positioning
Packaging Industry
Food vacuum packaging, modified atmosphere packaging
Electronics Industry
Automated production line suction, photovoltaic manufacturing
Printing Industry
Paper suction, printing roller pressing
Woodworking
CNC router table workpiece holding
Environmental Treatment
Wastewater aeration, material conveying
Company Introduction

Shenzhen Bebaios Machinery Co., Ltd. is a professional manufacturer and supplier specializing in industrial air compressor systems and pneumatic equipment. The company is located in Shenzhen, China - a global hub for advanced manufacturing and technological innovation. Leveraging the region's strong supply chain and manufacturing capabilities, Bebaios is committed to providing high-performance, energy-efficient air compression solutions to customers worldwide.

  • Quality Assurance:
    Consistent performance specification and compliance with international standards
  • Complete Service System:
    24-hour after-sales support system and strong customer service team providing precise and prompt responses to customer inquiries
Frequently Asked Questions
How do I choose the right model for my production line?

Model selection is primarily based on total pumping speed and required vacuum level. You can provide your equipment's total pumping speed (m³/h) and specific process pressure requirements, and we offer free sizing support. Our engineering team will calculate the appropriate safety factor to ensure neither oversizing (wasting energy) nor undersizing (affecting production).

What are the advantages compared to traditional rotary vane or piston vacuum pumps?

The main advantages are low noise, low energy consumption, and low maintenance costs. Compared to rotary vane pumps, the RV series eliminates wear-prone vanes and has much lower vibration. Compared to piston pumps, it provides smoother airflow pulsation and features a highly efficient oil-air separation system, resulting in cleaner exhaust and longer service life.

What payment terms do you accept?

Telegraphic Transfer (T/T).

How often should the oil separator and air filter be replaced? Are spare parts easy to purchase?

The air filter should be inspected every 1,000 hours and replaced approximately every 2,000 hours depending on operating conditions. The oil separator typically lasts 3,000 to 4,000 hours under normal oil quality. We support ERP traceability, and all spare parts are kept in stock and can be shipped quickly via our official website or local distributors.

Are operation manuals available? Is the control interface in English?

Standard units come with a bilingual (Chinese/English) intelligent touchscreen or text display. The operation manual is provided in both Chinese and English, and we can also customize other languages upon request.
